The becco Thru-axle M12 x 1.75 / 167-180 replaces your bike’s original thru-axle and provides an integrated attachment for the becco coupler system. The thru-axle and adapter are combined in one robust component, resulting in fewer parts, easier assembly, and exceptional reliability.



Top-quality material

The becco thru-axle is made from a 7075-T6 aluminum alloy, one of the strongest aluminum alloys available. This material is also used in aircraft construction and offers an exceptional combination of low weight and strength. The alloy can withstand significantly higher loads than standard aluminum alloys and is also corrosion-free, making it ideal for the demanding requirements of trailer operation.

The extra-thick hard-anodized coating provides additional protection against corrosion and wear. This advanced surface treatment hardens the outer layer, making it resistant to scratches and weather exposure. The result: a thru-axle that still looks and works like new even after years of intensive use.



Use

Simply replace your original axle with the thru-axle, and you can attach the becco towing part right away.
The integrated attachment for the becco towing part is precision-made and specifically designed for the becco coupler system. The becco towing part (included in the scope of delivery of your Qeridoo trailer or available separately) simply fits onto the head of the thru-axle and is secured in place. Together with your trailer’s becco tow bar, it creates a secure, comfortable connection that offers all the benefits of the innovative becco system:

  • Magnetically assisted clamping lever for effortless attachment
  • Integrated resonance damping for a smooth, stable ride
  • Separate alignment and fastening for precise positioning
  • The highest safety standards (in accordance with EN 15918)



Flexible length adjustment with a spacer system

The becco thru-axle comes with various spacers that allow you to adjust it precisely to your bike.

Included:

  • 2x flat spacer (2 mm) – for fine adjustments
  • 1x flat spacer (5 mm) – for larger length adjustments
  • 1x flat spacer (10 mm) – for larger length adjustments

By combining these spacers, you can set the effective length to 167, 170, 174, or 180 mm to fit your bike model precisely. The spacers ensure that the axle has the optimal installation length and that the wheel is installed securely without play.



Which bikes is this thru-axle suitable for?

The becco Thru-axle M12 x 1.75 / 167-180 fits all bikes with a 12 mm thru-axle and the Maxle standard (1.75 mm thread pitch) with installation lengths of 167, 170, 174, and 180 mm.



Difference between a thru-axle and a thru-axle coupler

  • Thru-axle (this product): replaces your original thru-axle and includes an integrated adapter for the becco towing part. The becco towing part is also required for a functional coupler.
  • Thru-axle coupler: complete set consisting of a thru-axle and becco towing part.



Important!

  • Before purchasing, measure the length of your original thru-axle and check the thread pitch. The becco thru-axle is available in various lengths and thread pitches to cover almost all common 12 mm standards.
  • Only the combination of a thru-axle and becco towing part forms a functional coupler on your bike.
  • Not suitable for bikes with carbon dropouts or a carbon rear frame (risk of breakage!).

Steckachse M12 x 1,75 / 167-180

The becco Thru-axle M12 x 1.75 / 167-180 is the solution for bikes with a thru-axle system. It replaces your bike’s thru-axle and has an integrated attachment for the becco towing part. Made from high-strength aluminum alloy with an extra-thick hard-anodized coating, it offers strength and durability. Fits 12 mm thru-axles with a 1.75 mm thread pitch in lengths of 167, 170, 174, and 180 mm. Together with the separately available becco towing part, it creates a secure connection to your trailer.
SKU B-TA12-25-BK175-180
GTIN 4260204182995
GPSR General Product Safety Regulation
Legal Warranty & Guarantee
69,00 €
incl. VAT (19%), plus shipping
Steckachse M12 x 1,75 / 167-180 at 69,00 €, quantity 1.
Free shipping from 100 €
In stock
Delivery time: 3 - 7 business days
Fri, Oct 30 - Thu, Nov 5
