The becco Thru-axle M12 x 1.75 / 209-229 replaces your bike’s original thru-axle and provides an integrated attachment for the becco coupler system. The thru-axle and adapter are combined in one robust component, giving you fewer parts, easier assembly, and maximum reliability.
Top-quality material
The becco Thru-axle is made from a 7075-T6 aluminum alloy, one of the strongest aluminum alloys available. This material is also used in aircraft manufacturing and offers an exceptional combination of light weight and strength. The alloy can withstand significantly higher loads than standard aluminum alloys and is also corrosion-free, making it ideal for the demanding requirements of trailer operation.
The extra-thick hard-anodized coating provides additional protection against corrosion and wear. This elaborate surface treatment hardens the outer layer, making it resistant to scratches and weather exposure. The result: a thru-axle that still looks and works like new even after years of intensive use.
Use
Simply install the thru-axle in place of your original axle, and you can attach the becco towing part.
The integrated attachment for the becco towing part is precisely manufactured and optimized for the becco coupler system. Simply place the becco towing part (included in the scope of delivery of your Qeridoo trailer or available separately) onto the head of the thru-axle and secure it. Together with your trailer’s becco tow bar, it creates a secure, comfortable connection that offers all the benefits of the innovative becco system:
- Magnetically assisted clamping lever for effortless attachment
- Integrated resonance damping for a smooth, stable ride
- Separate alignment and fastening for precise positioning
- Highest safety standards (according to EN 15918)
Flexible length adjustment with the spacer system
The becco Thru-axle comes with different spacers that allow you to adjust it precisely to your bike.
Included:
- 2x flat spacer (2 mm) – for fine adjustments
- 2x flat spacer (10 mm) – for larger length adjustments
By combining these spacers, you can set the effective length to 209, 217, or 229 mm to fit your bike model precisely. The spacers ensure that the axle has the optimal installation length and that the wheel is installed securely without play.
Which bikes is this thru-axle suitable for?
The becco Thru-axle M12 x 1.75 / 209-229 fits all bikes with a 12 mm thru-axle and the Maxle standard (1,75 mm thread pitch) with installation lengths of 209, 217, and 229 mm.
Difference between a thru-axle and a thru-axle coupler
- Thru-axle (this product): replaces your original thru-axle and includes an integrated adapter for the becco towing part. The becco towing part is also required for a functional coupler.
- Thru-axle coupler: complete set consisting of a thru-axle and becco towing part.
Important!
- Before purchasing, measure the length of your original thru-axle and check the thread pitch. The becco Thru-axle is available in different lengths and thread pitches to cover nearly all common 12 mm standards.
- Only the combination of a thru-axle and becco towing part creates a functional coupler on your bike.
- Not suitable for bikes with carbon dropouts or a carbon rear frame (risk of breakage!).
