Product name
Kidgoo 2 Pro Gen 2
Article numbers
Product description
The Kidgoo Pro takes everything that defines the Kidgoo to Pro level. More equipment, more control and even more comfort. Here the proven multitalent meets real pro features.
Intended use
The Qeridoo is designed as a bike trailer and is equipped with an additional stroller and walker mode.
The Qeridoo is intended exclusively for the private transport of one or two children on paved paths and may not be used under competition conditions. In addition, luggage may be carried in the designated compartments, provided that the permissible weight is observed and the luggage is safely stowed with even load distribution. Before using the Qeridoo, check which local regulations apply and how the product may be used.
Not permitted are operation on unpaved terrain, the transport of luggage in the cabin, the transport of animals, as well as
any commercial use. The specified performance limits must always be observed and checked before every use. Children may be transported up to a maximum body height of 116.5 cm. Only install and use original accessories and spare parts that are manufactured or recommended by Qeridoo. The use of other products, as well as any further manipulation carried out without the manufacturer's express written approval, will void liability in the event of accidents and defects.
Improper use
The Qeridoo may not be used for commercial purposes or under competition conditions. A careful riding style must always be maintained. This product is not suitable for jogging or skating without a jogger wheel. The included 14'' jogger wheel enables skating & jogging. The jogger and skater modes are not covered by the stroller certification.
Technical data
- Length trailer mode: 155 cm
- Empty weight trailer mode: 21.5 kg
- Maximum clearance width: 81 cm
- Push handle adjustment range: 62 - 122 cm
- Boot volume: 45 l
- Maximum body height: 116.5 cm
- Folded dimensions assembled (L x W x H): 108 x 76 x 47 cm
- Packaging dimensions (L x W x H): 103 x 72.5 x 41 cm
- Permissible total weight (Qeridoo + children + luggage): 60 kg
- Maximum payload (children + luggage): 38.5 kg
- Maximum payload in boot (luggage): 5 kg
- Maximum payload in foot area (luggage): 1 kg
- Maximum weight small storage bags: 0.5 kg
- Maximum weight per child: 22 kg
- Maximum weight of both children: 38.5 kg
- Age: 6 months – 6 years
- Permissible nose weight range (at tow bar head): 0 – 8 kg
- Minimum ambient temperature: -10 °C
- Towing vehicle type: bike, pedelec / e-bike (assistance up to 25 km/h)
- Maximum permissible top speed: 20 km/h, in curves max. 7 km/h
- Rear wheel size (towing vehicle): 25" – 29" (20" with tow bar for 20" bikes as accessory)
When accessories are used, their weight must be subtracted from the payload. The empty weight with mounted accessories plus payload must not exceed the permissible total weight. According to the German StVZO (Road Traffic Licensing Regulations | valid in Germany), a maximum total weight of 40 kg applies to unbraked trailers.
Safety and warning notices
WARNING!
- The safety and accident prevention regulations applicable in your region, as well as legal regulations such as the German Road Traffic Act (StVO), must additionally be observed and, in case of doubt, take precedence. Also inform yourself about country-specific regulations and traffic rules if you want to take the Qeridoo on trips abroad. Ensure that the Qeridoo is only used by persons who, as defined below, are suitable to operate it. Users must have read and understood this user manual in full.
- Packaging materials and protective caps must be removed and disposed of according to the environmental guidelines applicable in your region.
- The recommended tightening torques can be found at the following link: qeridoo.de/go/drehmomente
- All information on "Care & Maintenance" must be observed. Corrosion cannot be entirely ruled out. De-icing salts can lead to stress corrosion cracking.
- Never leave the child unattended. Do not let the child play with the product. The Qeridoo is not a children's toy and must not be misused as such. Accordingly, it is not permitted to attach the Qeridoo to a children's bike.
- Keep children away from the Qeridoo during assembly. When handling moving parts, take care not to pinch your hands and fingers. Before first use, check all screw and pin connections for tightness. Make sure that the child is out of reach when folding and unfolding the Qeridoo in order to avoid injury.
- This seat unit is not suitable for children under 6 months. Always use the restraint system.
- This product is not suitable for jogging or skating without a jogger wheel. The included 14'' jogger wheel enables skating & jogging. The jogger and skater modes are not covered by the stroller certification.
- Always make sure that the parking brake is applied when placing the child in and taking it out. Any loads attached to the push handle and/or to the back of the backrest and/or to the sides impair the stability of the Qeridoo.
- Only install and use original accessories and spare parts manufactured or recommended by Qeridoo. The use of other products will void liability.
- Wear marks can occur at the connection point between the bike frame and the coupler. This does not constitute a reason for complaint. Do not use any tool that has previously come into contact with conventional steel. The smallest steel particles could lead to contact corrosion.
- For operation of the rear light, observe the enclosed information from the manufacturer.
- Before use, make sure that the brake works properly. Despite a correct assembly procedure, the disc brake may start to drag. Readjust the brake calipers or have your trusted bicycle workshop help you.
DANGER!
- Before every use, make sure that all locks are engaged. Also wrap the safety strap of the tow bar around the tow bar in such a way that it does not hang down in the ready position and cannot get caught on obstacles or drag.
- Only one child may be transported in the Kidgoo 1 Pro (single seater) and a maximum of two children in the Kidgoo 2 Pro (two seater). They are secured by means of a harness system and wear suitable clothing as well as a bike helmet. Ensure even load distribution.
- The Qeridoo must not be used further after an accident! Even if no damage is externally visible, the protective effect may be impaired.
- Before every ride, make sure that the Qeridoo is in proper and technically faultless condition. Carry out a visual inspection and pay particular attention to the "Am I ready to go?" section. Also check that the side fixing is closed and the straps on the back of the seat bench are tightened.
- Always make sure that the safety strap is fastened before using the Qeridoo in trailer mode. Also make sure that it cannot get into moving parts of the towing bike.
- Do not use a washer or similar at the connection point between the bike frame and the coupler, as this can impair the stability of the connection.
- Always make sure that the foot parking brake audibly engages when activated. If it does not fully engage, the wheels are not securely locked and the Qeridoo can roll away.
Care and storage instructions
Care
After every use:
- Clean the interior of the cabin.
- Pay attention to heavy soiling and remove it as soon as possible.
After heavy weather exposure:
- Carry out a thorough interior and exterior cleaning of the cabin.
- Care for all sliding or moving parts with silicone spray.
- Only fold the cabin together when it has been cleaned and is completely dry.
- Wipe the frame and the entire cover dry.
When not in use:
- Only store the Qeridoo in places with a storage temperature in the range of -23 °C to a maximum of 65 °C.
- The trailer should only be stored when dry.
- The storage location should be dry, well-ventilated and protected from direct sunlight.
- At high storage temperatures, the wheels should be stored separately from the cabin, as the rubber of the tyres can lead to the formation of odours.
- Use a Qeridoo folding garage if the Qeridoo has to be stored outside.
Maintenance
Monthly (or every 200 km):
- Check the textile covers, all fasteners as well as the seats and safety harnesses for tears, wear and missing parts.
- Check all frame tubes as well as all connecting pieces and fastening components for signs of wear and damage.
- Check all screw and pin connections for tightness.
- Clean the wheel axles. Additionally, spray the axles with silicone spray.
Every six months (or every 500 km):
- Care for all sliding and moving parts with silicone spray.
- Carry out a thorough interior and exterior cleaning of the cabin.
- Check the spoke tension; it must be between 90 and 100 kg.
Every 2 years (or every 2,000 km):
- Replace the leaf springs, as they are a wear part.
Every 3 years (or every 3,000 km):
- At the latest every three years, have a complete inspection carried out by a specialist workshop.
Every 4 years (or every 4,000 km):
Conformity & safety
This product has been developed and manufactured in compliance with the applicable EU safety requirements. The materials used meet the relevant safety and quality standards.
Manufacturer information
Qeridoo GmbH
Industriepark Nord 100
53567 Buchholz, Germany
www.qeridoo.de
E-mail: info@qeridoo.de
Fax: +49 (0) 2683 9451925
